DISPLAY
|
Display Screen | 23.8” |
|---|---|---|
| Physical Resolution | 3840×2160, support 4K singal | |
| Aspect Ratio | 16:9 | |
| Brightness | 300cd/m² | |
| Contrast | 1000:1 | |
| Viewing Angle | 178°/178°(H/V) | |
|
INPUT
|
3G-SDI | 1 |
| HDMI | 4 (support 4K signal) | |
| DVI | 1 | |
| VGA | 1 | |
| Audio | 1 | |
| TALLY | 1 | |
|
OUTPUT
|
3G-SDI | 1 |
|
AUDIO
|
Speaker | 2 (L/R) |
| Ear Phone Slot | 1 | |
|
POWER
|
Current | 2800mA (15V) |
| Input Voltage | DC 12-24V (XLR) | |
| Battery Plate | V-mount / Anton Bauer mount | |
| Power Consumption | ≤36W | |
|
ENVIRONMENT
|
Operating Temperature | 0℃～60℃ |
| Storage Temperature | -20℃～60℃ | |
|
DIMENSION
|
Dimension(LWD) | 579×376.5×45mm / 666×416×173mm (with case) |
| Weight | 8.6kg / 17.1kg (with case) |
