Popis

Dimensions

Specification

Optical System	Focusable Fresnel
Lens Diameter	170 mm / 6.7″
Beam Angle	Rayzr 7 300:	18° – 55° (Half Peak Angle)
	Rayzr 7 300B:	18° – 50° (Half Peak Angle)
	Rayzr 7 200:	18° – 50° (Half Peak Angle)
	Rayzr 7 200BM:	18° – 50° (Half Peak Angle)
Weight	6.4 kg (14.1 lbs)
Mounting	16 mm / 28 mm Combo Pin （Baby 5/8 inch / Junior 1-1/8 inch Combo Pin）
Tilt Angle	90°
Power Supply Range	Rayzr 7 300(EU):	180 – 264 V AC, 50 – 60 Hz
	Rayzr 7 300(US):	90 – 132 V AC, 50 – 60 Hz
	Rayzr 7 300B:	95 – 280 V AC, 50 – 60 Hz
	Rayzr 7 200:	95 – 280 V AC, 50 – 60 Hz
	Rayzr 7 200BM:	95 – 280 V AC, 50 – 60 Hz
Power Consumption	Rayzr 7 300:	331 W Nominal, 352 W Maximum
	Rayzr 7 300B:	172 W Nominal, 192 W Maximum
	Rayzr 7 200:	204 W Nominal, 223 W Maximum
	Rayzr 7 200BM:	111 W Nominal, 115 W Maximum
Power Connection	Neutrik power CON TRUE1 NAC3MPX; Plug: Neutrik power CON TRUE1 NAC3FX-W
Battery DC Voltage Range	Rayzr 7 300:	24 – 36 V DC
	Rayzr 7 300B:	24 – 36 V DC
	Rayzr 7 200:	24 – 36 V DC
	Rayzr 7 200BM:	12 – 24 V DC
Battery DC Power Connection	Neutrik speak ON NL2MP; Plug: Neutrik speak ON NL2FX
White Light	Rayzr 7 300:	Daylight 5,600 K
	Rayzr 7 300B:	Bi-color 3,200 K to 5,600 K
	Rayzr 7 200:	Daylight 5,600 K
	Rayzr 7 200BM:	Bi-color 3,200 K to 5,600 K
Color Temperature Tolerance	100 K (nominal)
Color Rendition	TLCI 95 – 98, CRI 94 ± 1
Dimming	0 – 100% Continuous
Control	RJ – 45 DMX In and Through, On-Board Controller
Ambient Temperature Operation	-20 to +45º C (-4 to +113º F)
Protection Class	IP 20
Certifications	CE, FCC, RoHS, REACH
